Description
THIS CAN BE PICKED UP IN BROOKLYN…
Sand two grits in a single pass with a 37×2 Double Drum Sander. Featuring INTELLISAND® Technology and a 5 HP 220 Volt 1 phase motor, you can significantly reduce the amount of time you spend sanding.
The 37×2 Double Drum Sander features INTELLISAND® Technology that auto-regulates the conveyor based on load, preventing burning, gouging, and damaging stock.
Features
INTELLISAND® Technology: Automatically adjusts conveyor speed based on load
Prevents gouging, damaging or burning stock
Provides consistent finish even with varying grain pattern and density
Greatly increases abrasive planing and dimensioning speed
Flattness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections for no “flex” in conveyor, guaranteeing flatness to less than .010″ across the width of the sander
Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and overlap
Easiest access to abrasive fastening system of any drum sander! Machine design includes additional space around abrasive, eliminating the need for special tools.
Self-colling drum prevents overheating and extends abrasive life
Specifications
Sanding Capacity:
Max. Width: 37”
Min. Length: 3 1/2”
Max. Thickness: 12”
Min. Thickness: 1/32”
Dimensions (H x W x D): 43” x 58” x 31”
Drum: 5” x 37” Extruded Aluminum
Drum Speed: 1740 RPM
Dust Hood (Steel Hood, Hinged At Back): (3) 4″ Vacuum Ports, 1200 CFM Min. Recommended
Ball Bearing (1”): 4 Sealed and Permanently Lubricated
Conveyor Motor: 254 in./lbs. torque, direct drive D.C. motor, ranged variable, 0-15 FPM
Drive Motor (TEFC): 5 HP
Power Requirements: 208-230V, 60Hz, Single Phase, 30 Amp Service
Casters Included: Yes
Cord & Plug Included: No
Shipping Weight (lbs): 525
