Ligmatech Case Clamp (Used) Model: MPH-400; SN:xx-03-3783; Year: 2004.
Specifications:
-- (1) Horizontal & (1) vertical interlocked pressure beam, each with electric push button control; 8-beam surface area eliminates need for pressure pads.
-- Working capacity:
9.8" - 98.4" (250 - 2,500 mm) Length; 9.8" - 27.5" (250 - 700 mm) depth, 5.9" - 55" (150 - 1,400 mm) height.
-- Motorized horizontal & vertical beams can position simultaneously or individually during setup, vertical & horizontal interlocking pressure walls, each with (8) individual beams move parallel & square to the clamp frame;
(2) Selectable clamping speeds of approx. 5 FPM (1.5 MPM) or 10 FPM (3 MPM) and adjustable pneumatic pressure regulator clutch system stops the beams at preset pressure resistance.
